A Series Reciprocating Air Compressors

1 . Valve Assembly

All units use large disc-type valves made from swedish steel for high efficiency and long durability.

2. After Cooler

The copper tube is fitted with high-efficiency cooling fins that effectively reduce gas working temperature and increase air

compression efficiency.

3. Rings

Long life industrial design compression and oil control rings are used to assure maxi mum performance

4. Long-Life Cylinder

Precision-machined cylinder walls are honed glass-smooth to reduce friction and wear to a minimum. Extra-deep fins provide increased cooling and greater strength.

5. Continuous Running Unloader

For continuous-running air compressors. Unloader lets the unit idle load-free until air supply drops to cut-in pressure; automatically lets unit idle again after high pressure limit is reached. (Tubing and fitti ngs are not incl uded on bare pumps)

6. Balanced Fan-Type Flywheel

Airfoil-type spike provides a conti nuOUS powerful blast of cooling air for all parts Of the compressor. Balanced flywheel provides

smooth vibration less operation.

7. Cool Cylinder Head

Deep directional fins provide quick cooling. Compact streamlined air passages in the cylinder head permit fast, efficient flow of cooler inta ke and rapid removal of discharge air,
