CB SERIES

Ultimate solution for High-Pressure Air Boosting

FS-Curtis booster technology has consistently demonstrated its reliability over the years, whether it's used for blowing PET bottles, Laser cutting,pipeline testing or compressing nitrogen any application that demands high final pressures. The exceptional flexibility of the CB series high-pressure booster is what sets it apart. Regardless of the maximum compression ratio, it can achieve any final pressure between 15 and 40 bar, while the primary pressure can be adjusted between 5 and 12 bar.

The technological benefits of FS-CurtiS single-stage compressed booster are evident: along with its reduced energy consumption compared to multi-stage systems, it provides remarkable flexibility in choosing both primary and final pressures. These robust systems not only deliver excel- lent efficiency but also guarantee a long service life due to the use of premium components.

FEATURES AT A GLANCE COMPRESSOR BLOCK
Heavy duty cast-iron crankcase
Precisely machined and honed cast-iron cylinders and bare pumps with cooling fins
Dynamically balanced GGG60 cast crankshaft and counter weight
High capacity and high pressure-resistant inlet-outlet valves made from stainless steel
Compression and oil retaining rings

• Drive system with belt pulley mechanism

• Specially designed fan type cast iron pulley

• Easy belt tensioning system

• Automatic loadless start system

• IE3 efficiency-class electric motors

• Star/delta motor starter

• 2-stage aluminium radiator for Air and Oil cooling

• Bar-Plate outlet air cooling radiator

• Durable sliding bearings prolong maintenance periods and keep maintenance costs low.

• High performance with the high engineering technology and design.

• Oil-trap air filtration system provides cleaner air.

• Energy-saving advanced cooling systems.

• Intake air control system

• High pressure safety valve

• Manual drain valve

• Non-return valve

• Belt-pulley guard

• Outlet pressure gauges

• Air inlet and outlet hoses & connections

• Vibration pads

• Automatic discharge system for loadless start

• Low Speed operation

• Long-life bearings

• Air-cooled after cooler

• Air intake filter and silencer for loadless operation

• Oil splash lubrication system

• Oil level indicator

• Special discharge system preventing oil leakage from blow down valve.
