FAS 15-250KW

FAS 4 - 11 kW

The FAS product range includes air cooled, single stage silenced and packaged screw compressors in the power range of 4-11 kW. These compressors are designed for industrial application and 24×7 continuous duty. All models are driven by highly efficient IE3 efficiency class electric motors.

As an option, FAS compressors are available with pre-assembled accessories like:

• Air receiver
• Refrigeration dryer
• Pre & post downstream filters

Excellent quality

High quality components in combination with decades of experience in building air ends ensure durability with consistently high efficiency.

Integrated oil separator in the oil tank

The large oil tank is equipped with all necessary connections and safety installations and therefore ensures the highest operational safety. The internal high efficiency oil separator guarantees excellent compressed air quality with a remaining oil content of < 3 mg/m³.

Through an inspection glass, the oil level can be controlled at all times. Service can be conducted quickly and safely- the inlet neck as well as the oil drain valve can be easily accessed.

High performance suction filter

In all models, a high performance suction filter is installed. Sucked particles are filtered in two stages: first by centrifugal forces and second by a high efficiency filter element.

Electric motor

The driving motor conforms to energy efficiency class IE3, protection class IP55, insulation class F, and is thus most suited for rugged, continuous-duty industrial applications with the highest efficiency.

High efficiency cooling

The cooling system for both air and oil is designed so that the compressor can efficiently operate even at ambient temperatures of 45°C.
