FS-Curtis NxD and NxV

PROVEN PERFORMANCE
The FS-Curtis NxD and NxV Series rotary screw air compres- sors are valued worldwide for their legendary reliability and industrial performance.
Power efficiency is maximized with FS-Curtis' exclusive  airend profile, a premium efficiency motor, centrifugal fan, generously sized highest quality components and the intelli- gent controller that revolutionizes compressor operations by tracking temperature, pressure, and logging critical historical data.
Housed in a space-saving design and built for continuous, quiet operation, low ownership costs, easy service, and minimal downtime; the NX series delivers steady airflow with stable air pressure and outstanding quality air, with minimal oil carryover. Thus, making the NX Series the ideal choice for your industrial compressed air needs.
FEATURES AT A GLANCE
eCOOL® Technology

• Protects critical components from compressed generated heat

• Compartmentalized air flow design and oversized after cooler

• Extends component life and reduces lifetime

---

Ease of maintenance

• Easy access to all preventative maintenance components

• Washable cabinet pre-filter

• Controller alerts for maintenance intervals

• Differential pressure indicators for the oil filters, air filter & separator element

---

Optional Demandsmart energy management system

• Significantly reduces energy consumption at part load

• Reduces lifecycle costs by limiting energy consumption

• Fully enclosed variable drive enables reliable performance in harsh environments

• Precise air pressure control & Wide working pressure range

---

Dba shield noise reduction

• Extra thick sound installation

• Can be installed in applications where dBA level is critical

• Laminated oil-proof sound insulation

---

Energy Efficiency & Quality Components

• Precision built air end with patented 5:6 rotor profile with large rotor low-speed design offers maximum performance with lower energy consumption

• Premium Efficiency TEFC (IP55 Class F) motor

• Wye-Delta motor starter

• The separator, minimum pressure valve, and thermostatic valve are integrated, reducing the connections by up to 90%.

• Hi-Efficiency air/oil separator with 1–3 ppm carryover

• 100% continuous duty cycle, pulsation free air

• Energy efficient oversized cooler

• Built-in heavy duty air intake filter

• Additional heavy duty oil filter for added protection of airend bearings (On models from 110 kW and above)

• Durable powder-coat painted enclosure

• Leak-free design with O-ring seal fittings & hoses
