NXVi series

POWERFUL PERFORMANCE
FEATURES AT A GLANCE
New Integrated design of air end and PM motor

• Coupling free design offers best transmission efficiency

• High efficiency precision built air end with patented 5:6 rotor profile

• Efficiency of oil-cooled PM motor is close to IE5 efficiency class

• Maintenance free design reduces downtime

• Protects critical components from compressed generated heat

• Compartmentalized air flow design and oversized after cooler

• Extends component life and reduces lifetime

• Maintenance free patented intake valve with energy-saving design and streamline flow design reduces pressure loss, turbulence and noise.

• Air filter is made of multilayer nanocomposite material and has higher filtration levels, greater strength, longer service life, and significantly lower suction resistance.

• High efficiency integrated air/oil separator with 1–3 ppm carryover

• The separator, minimum pressure valve, and thermostatic valve are integrated, reducing the connections by up to 90%.

• Energy-efficient oversized cooler

• Heavy-duty industrial hose assemblies with leak-free fittings

• Durable powder-coat painted enclosure

• Non-asbestos gaskets with high temperature and pressure resistance are used to protect operators.

• Extra thick sound installation

• Axial fan with unique bionic design of blades reduces noise

• Independent air inlet with sound muffling

• Can be installed in applications where dBA level is critical

• Can be used as an onsite compressor to reduce losses due to leakages in pipeline

• Easy access to all preventative maintenance components

• Controller alerts for maintenance intervals

• Every component is meticulously designed to have minimal or no downtime

• Easy to install space-saving smaller footprint

• Intuitive and easy to use

• Variety of control, monitoring and protection features

• RS485 Modbus communication interface & sequence control

FS-Curtis NXVi Series air compressors are renowned world- wide for their legendary reliability and highly energy efficient operation. Equipped with an integrated patented advanced airend & an exceptionally efficient permanent magnet motor, a smart VFD, and an intelligent controller, FS Curtis NXVi series delivers unparalleled energy saving performance in the toughest conditions.

FS-Curtis NXVi Series air compressors operate at peak efficiency even with 80% reduction in air output and an advanced PID control algorithm helps to generate stable air pressure.

The compact vertical design saves valuable floor and work- space, provides easy maintenance access, and reduces total cost of ownership.

Count on Dependable FS Curtis NXVi series air compressors for steady performance, quiet operation, a quicker return on investment and unmatched durability.

Designed for maximum performance, energy efficiency with reliability

The ultimate in system protection & reliability

Build to the highest level of dependability and reliability

Designed for quieter operation

Designed for low cost of ownership, easy service, little and little down time
